GAI 5003A Vacuum Filler (2000)

GAI Vakuumfüller

Overview

GAI 5003A rinser-filler-corker monoblock built in 2000 for still wine in glass bottles. Rinser, gravity filler and corker are mounted on one frame inside a full guarding enclosure, rated at 5,000 bottles per hour for Burgundy and Bordeaux bottles. The sale includes an Etiquetadoras Jornet PR0504 self-adhesive labeller (2008) with three labelling stations.

Technical data

- Manufacturer: GAI
- Model: 5003A
- Year of manufacture: 2000
- Output: 5,000 bottles/h; speed range 1,200 - 6,000 bottles/h depending on format; max. 3,750 L/h
- Rinser: 20 grippers
- Filler: 20 gravity filling valves, vacuum pump on board
- Corker: 4-head turret for cork stoppers, with its own vacuum pump
- Bottles: Burgundy and Bordeaux; diameter 60 - 115 mm, height 200 - 400 mm
- Power supply: 380 V, 50 Hz, 3 phases + N, 24 V control voltage
- Installed power: 7.15 kW, 17 A, IP55
- Dimensions: approx. 4,050 x 1,690 x 2,270 - 2,550 mm (L x W x H)
- Conveyor height: 970 - 1,100 mm
- Weight: approx. 5,900 kg
- CE marked, CE declaration of conformity available

Scope of Delivery

- Rinser-filler-corker monoblock | GAI | 5003A | 20 grippers, 20 filling valves, 4 corking heads | 2000
- Self-adhesive labeller | Etiquetadoras Jornet | PR0504 | 3 stations (front, back, strip label), thermal printer | 2008

Equipment

- GAI control cabinet with operator keypad and display, emergency stop
- Electronic speed adjustment from the control panel
- Cork hopper feeding the corking turret
- Infeed screw and star wheels
- Filter units and pressure regulators with gauges
- Operating and maintenance manuals for both machines

Condition

Node Afltnjpfx Ap Eedc
Used machines, installed in a winery. Inspection on site is possible on request.

Availability

Available from end of January 2027. Location: Spain.
