Tavola rotante per saldatura, tavola rotante, posizionatore

Severt Hywema Sideros S40.1-1HH, 2 To Säulenhubdrehvorrichtung

SEVERT Double-Column Rotating Positioner S 40.1-1HH, 2 sets available, complete with documentation.
Suitable for welding or assembly operations. Can also be used as a single-column lifting and rotating device (mono configuration).
Giodpfx Ajyupkyjbxop

Total load capacity: 2000 daN
Load capacity per column: 1000 daN
Rotational torque at clamping plate 1: 1400 Nm
Clamping plate 2 rotates freely without drive
Clamping plate rotation speed: 2.0 min⁻¹
Clamping plate 1 dimensions: W1070 x H720 x D30 mm, part number 20452-001
Clamping plate 2 dimensions: W1070 x H720 x D30 mm, part number 20453-001
Lift travel: 680 mm
Lifting speed: 2200 mm/min
Welding current transfer: 400 A

B2 Dimensions:
Column 1 with base:
Length: 970 mm
Width: 885 mm
Height: 2350 mm
Net weight: 1200 kg

Column 2 with chassis:
Length: 970 mm
Width: 1030 mm
Height: 2350 mm
Net weight: 1600 kg

Top condition, complete documentation available.
We have several column lift and rotating positioners in stock from 1 ton to 15 tons load capacity.
2 complete sets (units) are available.
